Track Skid Steer

Track Skid Steer

John Deere

EquipmentEquipment

2023 John Deere 325G Compact Track Loader Gross Power: 54.8 kW (74 hp) Net Power: 52.5 kW (70 hp) Rated Operating Capacity: 1 176 kg (2,590 lb.) Operating Weight: 4 313 kg (9,500 lb.) Has AC and Heat, Heated seat with air ride. Radio. Two speed. Length - No Bucket, mm (inches) 2850 (112.3) Length - Foundry Bucket, mm (inches) 3460 (136.3) Width - No Bucket, mm (inches) 1820 (71.5) Height - Top Of Cab, mm (inches) 2060 (81.1) Ground Clearance, mm (inches) 240 (9.3) Rear Departure Angle, Degrees 30.5 Height to Hinge Pin, mm (inches) 3200 (126.1) Dump Angle, Degrees 41 Dump Height - Maximum Foundry, mm (inches) 2590 (102.1) Rollback - Ground Level, Degrees 34 DIMENSIONS Fuel Tank, ltr (gallons (US)) 79 (21) CAPACITIES Rated Operating Capacity - Foundry, kg (lbs) 1176 (2590) Tipping Load - Foundry, kg (lbs) 3360 (7400) Ground Bearing Pressure - Foundry, kPa (PSI) 39.3 (5.7) Speed - Maximum, kph (mph) 13.2 (8.2) Breakout - Lift Foundry, kN (lbf) 23.3 (5250) Breakout - Bucket Foundry, kN (lbf) 38.9 (8750) Hydraulic Power, kW (hp) 30.617 (41) Hydraulic Power - Option, kW (hp) 47.103 (63.1) Pump Flow, lt/min (gallons (US) / min) 78 (21) Pump Flow - Option, lt/min (gallons (US) / min) 120 (32) System Pressure, bar (PSI) 237.87 (3450) PERFORMANCE Operating Weight - Foundry, kg (lbs) 4313 (9500) WEIGHTS
