LIFT - GENIE 26ft MICRO BOOM for rent in Edmonds, Washington

LIFT - GENIE 26ft MICRO BOOM

GENIE

Equipment,ToolsEquipment,Tools

GENIE MODEL GR26J *NOTE: THIS UNIT HAS WHITE SOLID NON-MARKING TIRES MADE TO BE USED INDOORS ON FINISHED FLAT SURFACES, *NOT FOR ROUGH TERRAIN!* ...... NOTE: WEIGHS 6251 LBS MUST BE SENT OUT ON THE HYDRAULIC TRAILER, NOT A REDI HAUL TRAILER (DOESN'T CLIMB TRAILER RAMPS EASILY)........ Width 99 cm 3 ft 3 in Working height maximum* 9.85 m 32 ft 4 in Platform height maximum 7.85 m 25 ft 9 in Horizontal reach maximum 2.65 m 8 ft 8 in Working horizontal reach maximum 3.15 m 10 ft 3 in Up-and-over clearance maximum 6.70 m 21 ft 10.5 in Platform length 75 cm 2 ft 5.5 in Platform width 90 cm 2 ft 11 in Toeboard height 15 cm 6 in Height - stowed 1.99 m 6 ft 6 in Length - stowed 2.82 m 9 ft 3 in Width 99 cm 3 ft 3 in Weight 6251 lbs Wheelbase 1.20 m 3 ft 11 in Ground clearance - centre 10 cm 4 in Maximum platform occupancy (indoor/outdoor) 2/1 Lift capacity 200 kg 440 lbs Vertical jib rotation 140 (+70 /-70 ) Turntable rotation 350 non-continuous Turntable tailswing 9 cm 3.74 in Drive speed - stowed 4.5 km/h 2.8 mph Drive speed - raised 0.65 km/h 0.4 mph Gradeability** 25% Turning radius - inside 59 cm 1 ft 11 in Turning radius - outside 2.08 m 6 ft 10 in Raise / lower speed 54 s/40 s 54 s/40 s Controls 24 V DC proportional Drive dual rear wheel Disc brakes dual rear wheel Tyres (solid non-marking) 40.5 cm diam. 16-5-11 Power source 24 V DC (twelve 2 V batteries, 250 Ah capacity) Hydraulic system capacity 22 L 4.84 gal 22 L 4.84 gal
